Supercore Part Number: 1ZUN18S-544800-A1



- Comp Wheel: 48/60mm

Trim: 65

A/R: 0.7



- Turbine Wheel: 54/49mm

Trim: 84



- Horsepower: 300-550hp

- Displacement: 1.4L-3.0L

- Bearing: Dual-row ceramic ball bearing


The following components are not included as part of the Super-Core: Turbine Housing, Clamp Plate Hardware, Wastegate, and Actuator.

This GTX Hybrid series is paired with the GTX cartridge, this allows GTX turbos to upgrade to G Series at minimal cost!

Below items are turbine housings and actuators that we recommend to go with the Super-Core at additional cost.

● Scrollable Table for Turbine kit details:

Turbine kit PN A/R Inlet Outlet Wastegate Divided
1GTBH-UN19ZG49-0100 0.64 T25 5 Bolt wastegated N
1GTBH-UN20ZG49-0100 0.86 T25 5 Bolt wastegated N
1GTBH-GA22ZG49-0100 0.72 v-band v-band wastegated N
1GTBH-GA17ZG49-0100 0.92 v-band v-band wastegated N



● Carefully assembled and VSR balanced by balancing machine from Turbo Technics in our fully equipped Taiwan facility.

● ZAGE can ship worldwide with no minimum order quantity.

● For bulk-buy B2B trade, please contact sales1@zageturbo.com for more information.
