Supercore Part Number : 1ZUN8S-596100-A1
Comp Wheel: 62/76mm
Trim: 65
A/R : 0.72
Turbine Wheel: 60/55mm
Trim: 84
Horsepower: 550-900hp
Displacement: 2.0L-3.5L
The following components are not included as part of the Super-Core: Turbine Housing, Clamp Plate Hardware, Wastegate, and Actuator.
Zage G Series wheels are compatible with only GTX cartridges, this allows GTX turbos to upgrade to G Series at minimal cost!
*** ZAGE can ship worldwide with no minimum order quantity. ***
Below items are turbine housings and actuators that we recommend to go with the Super-Core at additional cost.
| Turbine kit PN | A/R | Inlet | Outlet | Wastegate | Divided | |
| 1GTBH-GA23ZG55-0100 | 0.49 | T25 | v-band | wastegated | N | |
| 1GTBH-GA21ZG55-0100 | 0.72 | v-band | v-band | Free Float | N | |
| 1GTBH-GA16ZG55-0100 | 0.92 | v-band | v-band | Free Float | N | |
| 1GTBH-GA3ZG55-0100 | 0.61 | V-Band | V-Band | Free Float | Y | |
| 1GTBH-GA4ZG55-0100 | 0.83 | V-Band | V-Band | Free Float | Y | |
| 1GTBH-GA5ZG55-0100 | 1.01 | V-Band | V-Band | Free Float | Y | |
| 1GTBH-GA6ZG55-0100 | 0.61 | V-Band | V-Band | Free Float | N | |
| 1GTBH-GA7ZG55-0100 | 0.83 | V-Band | V-Band | Free Float | N | |
| 1GTBH-GA8ZG55-0100 | 1.01 | V-Band | V-Band | Free Float | N | |
| 1GTBH-GA9ZG55-0100 | 0.61 | T3 | V-Band | Free Float | Y | |
| 1GTBH-GA10ZG55-0100 | 0.83 | T3 | V-Band | Free Float | Y | |
| 1GTBH-GA11ZG55-0100 | 1.01 | T3 | V-Band | Free Float | Y | |
| 1GTBH-NI5ZG55-0102 | 0.64 | T25 | 5 Bolt | Wastegated | N | |
| 1GTBH-NI5ZG55-0201 | 0.64 | V-Band | 5 Bolt | Wastegated | N | |
| 1GTBH-SU1ZG55-0100 | 7cm2 | Subaru | 5 Bolt | Wastegated | N | |
| 1GTBH-SU5ZG55-0100 | 10cm2 | Subaru | 5 Bolt | Wastegated | N | |
| 1GTBH-SU7ZG55-0100 | 8cm2 | Subaru | 5 Bolt | Wastegated | N | |
| 1GTBH-UN506355-0100 | 0.63 | V-Band | V-Band | Free Float | N | |
| 1GTBH-UN508255-0101 | 0.82 | V-Band | V-Band | Free Float | N | |
| 1GTBH-UN510655-0101 | 1.06 | V-Band | V-Band | Free Float | N | |
| 1GTBH-UN606355-0100 | 0.63 | T3 | V-Band | Free Float | N | |
| 1GTBH-UN608255-0101 | 0.82 | T3 | V-Band | Free Float | N | |
| 1GTBH-UN610655-0100 | 1.06 | T3 | V-Band | Free Float | N | |
