Flange: STRAIGHT
Actuator: 0.2~2 BAR
APPLICATIONS:
1998- Volvo S70, XC70, V70, 850 Engine B5254T
- Bearing: Dual-row ceramic ball bearing
Replacement for: Stock TD04HL Turbo P/N 49189-01365, 49189-01360, 49189-01450, 49189-01455 etc.
*STOCK MHI TD04HL-16T TURBO MAX 250HP.
● You're welcome to contact us for customizing your own configurations.
● Scrollable Table for Turbo Configurations:
Max HP | Turbine Wheel | Nozzle Area | AR | Compressor Wheel | CFM | Part Number |
---|---|---|---|---|---|---|
290+ | TD04HL (45.6/52mm) | 6cm² | 41 | 19T (46/58 mm) | 450 | 1ZVO1I-534606-02 |
250+ | TD04HL (45.6/52mm) | 6cm² | 41 | 16T (43.4/56 mm) | 450 | 1ZVO1I-534306-02 |
● Carefully assembled and VSR balanced by balancing machine from Turbo Technics in our fully equipped Taiwan facility.
● ZAGE can ship worldwide with no minimum order quantity.
● For bulk-buy B2B trade, please contact sales1@zageturbo.com for more information.
